The ASUS TUF GAMING X570-PLUS (WI-FI) motherboard user manual provides installation, BIOS setup, and specifications.
This guide covers everything needed to install and configure the TUF GAMING X570-PLUS (WI-FI) motherboard, including safety information, hardware layout, CPU and memory installation, and connector descriptions. It also explains BIOS setup, RAID support, and troubleshooting steps.
The manual includes detailed specifications such as supported CPUs, memory types, expansion slots, storage options, networking, audio, and USB ports, as well as ASUS‑specific features like TUF protection, Aura lighting, and AI Suite utilities.
| CPU socket | AM4 |
|---|---|
| Chipset | AMD X570 |
| Memory capacity | 4 DIMM, up to 128 GB DDR4 |
| PCIe slots | 1 x PCIe 4.0/3.0 x16 |
| SATA ports | 8 x SATA 6 Gb/s |
| LAN controller | Realtek L8200A |
| Wi‑Fi module | Intel Wireless‑AC 9260 (Wi‑Fi 5) |
| Audio codec | Realtek S1200A 8‑channel |
| Form factor | ATX |
Disconnect the power cable from the outlet, avoid short circuits by keeping metal objects away from connectors, and ensure the system is placed on a stable, dry surface.
The motherboard provides eight SATA 6 Gb/s ports.
It includes an Intel Wireless‑AC 9260 2×2 Wi‑Fi 5 module.
It uses an AM4 socket compatible with AMD Ryzen 2nd and 3rd generation processors.
