A solution guide from Analog Devices describing system architecture, design challenges, and component recommendations for biochemical analyzers.
The document presents a comprehensive solution for biochemical analyzers, covering the overall system architecture, key subsystems such as the optical engine, sample handling, temperature control, power management, and motor control. It outlines design considerations, main challenges, and provides recommended Analog Devices components for each functional block.
Additional sections list detailed part numbers, performance highlights, and design resources including application notes, reference designs, and software tools to aid developers in implementing the solution. This manual is written in Chinese.
| Maximum sample throughput (large analyzer) | over 600 samples per hour |
|---|---|
| Temperature accuracy | 0.1 °C |
| ADC resolution used in signal chain | 18‑bit, 5 MSPS |
| Optical measurement techniques | colorimetry, absorbance, spectrophotometry, transillumination |
The temperature accuracy is up to 0.1 °C.
It can process more than 600 samples per hour.
The analyzer uses colorimetry, absorbance, spectrophotometry and transillumination.
