The ABIT VT7 Socket 478 motherboard user manual provides installation, BIOS setup, and hardware configuration instructions.
This manual covers the VT7 Socket 478 motherboard from ABIT, detailing its features, specifications, and step‑by‑step hardware installation procedures. It includes sections on CPU installation, memory configuration, peripheral connections, and BIOS options.
Additional information such as driver installation, troubleshooting, and technical support contacts are provided in the appendices, helping users set up and maintain the system efficiently. This manual is written in Chinese.
| CPU Support | Intel Pentium 4 Socket 478, 800/533/400 MHz bus |
|---|---|
| Chipset | VIA PT880 + VT8237 |
| Memory Slots | 4 × 184‑pin DIMM, Un‑buffered, Non‑ECC, Dual DDR 400/333/266, up to 4 GB |
| AGP Slot | AGP 8X/4X, 0.8 V/1.5 V |
| Serial ATA | 2 × Serial ATA 150 MB/s with RAID 0/1 |
| Audio | Six‑channel AC97 CODEC with S/PDIF I/O |
| LAN | 10/100 Mbps Ethernet controller |
| USB | USB 2.0 (v2.0) ports |
