The ABIT BF6 motherboard user manual provides specifications, hardware installation, BIOS setup, and troubleshooting guidance.
This manual covers the BF6 motherboard’s specifications, hardware installation steps, BIOS configuration, and a range of troubleshooting procedures. It includes detailed diagrams of component locations, system block diagrams, and instructions for installing CPUs, memory, and peripheral devices.
The document also describes supported CPUs, memory limits, chipset features, I/O ports, power‑management options, and Wake‑On‑LAN functionality, helping users configure the board for optimal performance and stability. This manual is written in Chinese.
| Supported CPUs | Intel Pentium III 450‑800 MHz, Intel Pentium II 233‑450 MHz, Intel Celeron 266‑433 MHz (Slot 1), Intel Celeron 300A‑533 MHz (Socket 370) |
|---|---|
| Chipset | Intel 440BX (82443BX and 82371EB) |
| Maximum Memory | 768 MB |
| BIOS | Award BIOS 6.0 with CPU Soft Menu™ III |
| I/O Ports | 2 Bus Master IDE connectors (up to 4 Ultra DMA 33 devices), PS/2 keyboard & mouse, 16550A UART serial, USB ports |
| Wake‑On‑LAN | Supported |
It supports Intel Pentium III 450‑800 MHz, Intel Pentium II 233‑450 MHz, Intel Celeron 266‑433 MHz (Slot 1) and Intel Celeron 300A‑533 MHz (Socket 370).
The board can accommodate up to 768 MB of system memory.
Yes, the BF6 includes built‑in network wake‑up (Wake‑On‑LAN) functionality.
It uses Award BIOS 6.0 with CPU Soft Menu™ III technology.
