TP UP-AF series of high-speed panel-mounted miniature printers adopt high-speed impact dot matrix printing, a new panel structure, which is particularly suitable for installation on the vertical panel of instruments and equipment as a printing output device, and become one with the instrument and equipment.
The TP UP-AF series is a high‑speed, panel‑mount micro printer that uses needle‑impact dot matrix printing. It is designed for vertical panel installation on measurement instruments, recorders and billing devices, and supports both serial and parallel interfaces as well as Chinese character printing.
The manual provides detailed specifications, step‑by‑step installation of power, ribbon and paper, interface wiring, command descriptions, self‑test procedures and performance data such as print speed, resolution, dimensions and power requirements. This manual is written in Chinese.
| Dimensions (W×D×H) | 122 mm × 90 mm × 129 mm |
|---|---|
| Weight | ≈350 g (without paper roll) |
| Ribbon types | ERC‑09 (25 × 10⁴ chars), ERC‑22 (100 × 10⁴ chars) |
| Operating environment | 0 °C – 40 °C, 5 % – 85 % RH |
The printer offers a serial RS‑232C interface (IDC‑10) and an 8‑bit parallel interface (IDC‑26). The desired interface is chosen by moving short‑circuit block W3 on the control board.
