The Winmate TPC08-I98MU1 is a solid‑type flat tablet computer featuring an 8.4" SVGA LED panel, Intel Atom Z530 1.6 GHz processor, and optional 4‑wire resistive touchscreen. It supports 802.11b/g Wi‑Fi, Bluetooth, and a 6‑cell 5200 mAh Li‑ion battery for up to 8 hours of use.
This manual lists the device’s hardware specifications, connector layout, environmental ratings, and power requirements. It also includes contact information for further product support. This manual is written in Chinese.
| Processor | Intel Atom Z530 1.6 GHz |
|---|---|
| BIOS | AMI system BIOS |
| Chipset | US15W |
| Memory | DDR2 667 SODIMM, up to 2 GB |
| Storage Options | 2.5" SATA HDD (160 GB default), industrial CF, automotive HDD or SSD |
| Display Size | 8.4" SVGA LED panel |
| Resolution | 800 × 600 |
| Brightness | 350 nit |
| Touchscreen | 4‑wire resistive, optional sunlight readable |
| Wireless | 802.11b/g Wi‑Fi and Bluetooth |
| Battery | 6‑cell 5200 mAh Li‑ion, 11.1 V |
| Battery Runtime | ≈8 hours |
| Power Consumption | 9 W |
| Dimensions | 259 mm × 215 mm × 45 mm |
| Weight | 2.0 kg (without accessories) |
| Operating Temperature (HDD) | -10 °C to 55 °C |
| Operating Temperature (SSD) | -20 °C to 60 °C |
| Relative Humidity | 10 %–90 % non‑condensing |
| Ingress Protection | IP54 |
| Shock Rating | MIL‑STD‑810F 516.5 |
| Vibration Rating | MIL‑STD‑810F 514.5 |
| Drop Rating | MIL‑STD‑810F 516.5 |
| Certifications | CE, FCC Class B, 3C |
It uses an Intel Atom Z530 processor running at 1.6 GHz.
The 5200 mAh Li‑ion battery provides about 8 hours of operation.
It supports 802.11b/g Wi‑Fi and Bluetooth.
With an HDD it operates from –10 °C to 55 °C; with an SSD from –20 °C to 60 °C.
