The SY210NT series controller is part of the SY series products, which mainly include SY210NT series induction controller, SYRD series induction card reader, MDDIDO-1S module, MDPRINT-1S module, and induction card, etc. This document describes the connection methods and usage of the products.
This manual introduces the SY210NT series induction controller, its system architecture, and compatible modules such as card readers, DIDO modules, and printer modules. It includes detailed diagrams for device connections, wiring tables, and the main functional flow of the system.
The guide walks users through initial power‑up, fault detection, password login (default 1234), ID configuration for controllers and card readers, module plug‑and‑play procedures, and basic operation settings like DO/DI scheduling, print modes, and alarm configuration. This manual is written in Chinese.
| Power input voltage | 5 ~ 12 V DC |
|---|---|
| Controller current consumption | 400 mA (per unit) |
| Card reader current consumption | 100 mA (per unit) |
| Maximum RS‑485 cable length | 1 km |
A single management computer can connect up to 99 controllers in a parallel (bus) configuration.
The default password for the first login is 1234.
Use shielded twisted‑pair cable, preferably AWG18‑22, for RS‑485 transmission.
A controller can support up to 8 card readers, connected in parallel.
