GH-PCU23-VE cooler has a dual rocket wind hood intake design, four high-conductivity heat pipe designs, a precision-forged high-density copper base, super-large aluminum fins, a wider heat dissipation area, and a linear fan controller (can be installed on the 3.5'' front panel or rear PCI bracket). ), replaceable fluorescent sensing ring (blue / green / white / orange).
The GH‑PCU23‑VE heatsink comes with a full set of accessories, including the heatsink itself, user manual, thermal paste, fan speed controller, and mounting brackets for Intel LGA775, mPGA478, and AMD AM2/K8 platforms. The guide lists each item and provides detailed installation procedures for each supported CPU socket.
The document also details the power connection, fan speed controller mounting, and unique design features such as replaceable fluorescent rings and dual‑rocket air‑shroud design. Technical specifications such as dimensions, fan size, and performance ratings are provided for reference. This manual is written in Chinese.
| Heatsink dimensions | 112 x 112 x 175 mm |
|---|---|
| Fan dimensions | 92 x 92 x 25 mm |
| Number of heat pipes | 4 |
| Rated voltage | 12 V |
| Rated current | 0.38 A |
| Fan speed | 1,500 ~ 3,000 RPM |
| Noise level | 16 ~ 33.5 dBA |
| Bearing type | Ball bearing |
| Fan lifespan | 50,000 hours |
The package contains the GH‑PCU23‑VE heatsink, user manual, thermal paste, a 3.5" fan speed controller, a PCI bracket, power cable, LGA775 bracket, P4 bracket, and AM2/K8 brackets.
