The DocuCentre-II 5010/4000 Digital Multifunction System is a compact, feature-rich printer, copier, scanner and fax machine. It offers the latest technology to help you improve your productivity. The machine also comes with enhanced “smart” security features to protect your documents and network.
The DocuCentre‑II 5010/4000 series combines fast printing (up to 55 ppm), high‑quality 600 dpi output and optional 1200 dpi image reproduction with advanced security functions such as hard‑drive overwrite and secure watermarking. It supports multiple paper trays, optional high‑capacity feeders and three synchronous G3 fax lines for efficient office workflow.
Designed for productivity, the machine offers a 30‑second warm‑up, 3.2 s first‑page copy time, and scanning speeds of up to 55 ipm (5010) or 52 ipm (4000). It integrates with network services (SMB, FTP, Citrix MetaFrame) and includes optional software for secure watermark analysis and document management. This manual is written in Chinese.
| Print speed | 55 ppm (5010) / 45 ppm (4000) |
|---|---|
| Warm‑up time | 30 seconds |
| Memory (standard / max) | 256 MB / 512 MB |
| Hard‑drive capacity | 40 GB |
| Maximum power consumption | 1.76 kVA (220 V) / 1.92 kVA (240 V) |
| Dimensions (W × D × H) | 640 mm × 652 mm × 832 mm |
| Fax lines | Up to 3 synchronous G3 lines |
The machine warms up in 30 seconds.
It scans at up to 55 ipm for the 5010 model and 52 ipm for the 4000 model.
It can be equipped with up to three synchronous G3 fax lines.
