DocuScan C1500 is a large-format color scanner with high-resolution and fast scanning capabilities, which can process color drawings, blueprints, underlays, black and white drawings, photos and other paper documents.
The DocuScan C1500 is a large‑format color scanner capable of handling color drawings, blueprints, photos and other paper documents. It offers high‑resolution 600 × 600 dpi scanning and fast speeds of up to 3.0 m/min for color and 9.1 m/min for black‑and‑white.
This manual describes the scanner’s technical specifications, supported software (USB TWAIN driver and DW‑Scan3 Service), connection options, power requirements, physical dimensions and how to operate the device safely and efficiently. This manual is written in Chinese.
| Optical resolution | 600 × 600 dpi |
|---|---|
| Color scanning speed | 3.0 m/min |
| Black‑and‑white scanning speed | 9.1 m/min |
| Color depth | 24‑bit true color |
| Data acquisition depth | 12‑bit |
| Data output depth | 8‑bit |
| Interface | USB 2.0 (high speed) |
| Dimensions (L × W × H) | 1200 mm × 595 mm × 1064 mm |
| Weight | 45 kg (without stand) |
The scanner can capture color images at a speed of 3.0 meters per minute at 600 × 600 dpi.
The scanner measures 1200 mm in length, 595 mm in width, and 1064 mm in height.
