This document introduces the features and characteristics of Fuji servo system, including operation and display, model description, system configuration diagram, specifications of servo motor and servo amplifier, etc. The servo system has features such as simple debugging, high-resolution encoder, trial run function, etc., making it suitable for a wide range of applications.
The Fuji FALDIC-W servo system manual provides detailed information on system features, model variants, and component specifications. It includes system diagrams, motor and amplifier data, wiring connections, and dimensional drawings.
The document also describes debugging functions, high‑resolution encoder usage, vibration‑reduction control, monitoring outputs, and warranty terms. It is intended for end‑users and service technicians who need to install, operate, and maintain the servo system. This manual is written in Chinese.
| Rated Output | ʤL8ʥ |
|---|---|
| Rated Speed | ʤS0NJOʥ |
| Communication Interfaces | 34 |
| Power Supply Options | Single‑phase or three‑phase |
The system can be powered by either single‑phase or three‑phase supplies.
It provides 34 communication interfaces for connecting to external devices.
Warranty is one year from purchase or 24 months from the production date, whichever comes first.
