ApeosPort-II 5010/4000 is a high-end business multifunction device that provides fast printing, copying, scanning and faxing functions, as well as a variety of intelligent services to achieve seamless information integration and management.
The ApeosPort-II 5010/4000 is a digital multifunction machine that combines high‑speed printing, scanning, copying and faxing in one device. It supports up to 55 ppm printing and 55 ipm scanning, with a maximum resolution of 600 × 600 dpi and optional 1 200 × 1 200 dpi image quality.
The machine offers extensive paper handling options, multiple security features such as password‑protected printing and secure fax, and integration with network services like FTP, SMB, WebDAV and Citrix. Optional accessories include high‑capacity paper feeders, various binders and advanced document‑flow software. This manual is written in Chinese.
| Print speed | 55 ppm |
|---|---|
| Resolution | 600 × 600 dpi (up to 1 200 × 1 200 dpi) |
| Optional high‑capacity feeder | 2 000 sheets |
| Supported paper weight | 60 gsm – 216 gsm |
| Power consumption | 1.76 kVA (220 V) / 1.92 kVA (240 V) |
| Dimensions (W × D × H) | 640 × 678 × 832 mm |
| Processor | PowerPC‑750Cx‑600 MHz |
| Memory | 512 MB (max) |
| Hard disk | 40 GB (standard) |
| Network interfaces | 100Base‑TX/10BASE‑T, IEEE 1284 parallel, USB 2.0 |
| Supported operating systems | Windows 2000/XP/Server 2003/Vista, Mac OS |
It can print up to 55 pages per minute.
It includes password‑protected printing, secure fax, data overwrite, encrypted email/FTP/SMB transfers and secure document storage.
Scanning is supported up to 600 × 600 dpi (with optional higher settings for image quality).
