P5B-E Plus motherboard user manual, introduces the characteristics and features of the motherboard, installation, use methods, etc.
This manual introduces the ASUS P5B-E Plus motherboard, its key features, and safety guidelines. It covers hardware installation steps such as CPU, memory, and expansion card placement, as well as detailed BIOS configuration options.
Additional sections describe software support, RAID functionality, and advanced features like Hyper‑Threading and Intel SpeedStep. The document also includes troubleshooting tips and a list of utilities for system maintenance. This manual is written in Chinese.
| CPU socket | 775 |
|---|---|
| Supported CPU | Intel Pentium 4 |
| Hyper‑Threading support | Yes |
| PCI Express x1 | Supported |
| PCI Express x4 | Supported |
| PCI Express x16 | Supported |
| RAID functionality | Supported |
| SATA ports | 1‑6 |
Enter the BIOS Advanced menu, locate the Hyper‑Threading Technology option, and set it to Enabled.
The motherboard uses a 775 socket for Intel Pentium 4 processors.
Use the RAID configuration section in the BIOS and install the appropriate RAID drivers from the Drivers menu.
