The Colorful C.PE800 Overclocking Warrior 3 motherboard is an ATX motherboard that uses a new chipset and provides new features. This motherboard supports Intel Socket 478 Pentium 4 processors and features super I/O functionality, AGP interface, built-in AC'97 Codec controller, and more.
The manual introduces the Colorful C.PE800 ATX motherboard, its layout, and the components it supports. It lists the supported processors, chipset, memory types, and expansion interfaces.
It also provides detailed BIOS configuration steps, hardware installation procedures, driver installation, and troubleshooting of common POST error beeps. This manual is written in Chinese.
| CPU socket | Socket 478 |
|---|---|
| DIMM slots | 2 (184‑pin) |
| Memory voltage | 2.5 V DDR SDRAM |
| Maximum memory | 2 GB DDR |
| Memory speed | DDR400 up to 166 MHz |
| AGP version | AGP 4X, 1.5 V only |
| USB ports | 6 (USB 2.0) |
| Ultra DMA modes | 33/66/100 |
| Audio codec | AC'97 |
| Power management | ACPI 1.0B, APM 1.2 |
| Board dimensions | 305 mm × 208 mm |
It uses the Award Plug‑and‑Play BIOS.
The board includes six USB 2.0 ports.
Up to 2 GB of DDR memory can be installed.
