This manual introduces the MICROMASTER series of frequency converters, covering four models (410, 420, 430, 440) with power ranges from 0.12 kW up to 250 kW. It describes typical applications such as pumps, fans, conveyors, and industrial machinery, and lists the available supply voltages for single‑phase and three‑phase operation.
The document contains detailed wiring diagrams, technical specifications, selection and ordering data, optional modules (e.g., PROFIBUS, DeviceNet, encoder modules), and service procedures. It also includes dimensions, cooling information, EMC compliance, and warranty/repair instructions for field service. This manual is written in Chinese.
| MICROMASTER 410 power range | 0.12 kW to 0.75 kW |
|---|---|
| MICROMASTER 420 power range | 0.12 kW to 11 kW |
| MICROMASTER 430 power range | 7.5 kW to 90 kW |
| MICROMASTER 440 power range | 0.12 kW to 250 kW |
| Supply voltage (single‑phase) | 100 V to 120 V |
| Supply voltage (single‑phase) | 200 V to 240 V |
| Supply voltage (three‑phase) | 380 V to 480 V |
| Digital inputs (410/420) | 3 |
| Digital inputs (430/440) | 6 |
| Analog inputs (410/420) | 1 |
| Analog inputs (430/440) | 2 |
| Relay outputs (410/420) | 1 |
| Relay outputs (430/440) | 3 |
The MICROMASTER 410 supports power from 0.12 kW up to 0.75 kW.
The MICROMASTER 430 provides six digital inputs.
Optional modules include PROFIBUS, DeviceNet, and pulse‑encoder/counting modules.
