This datasheet provides detailed information about the LM3S8970 microcontroller, including product features, target applications, high-level block diagram, functional overview, ARM Cortex™-M3 processor core, memory map, interrupts and JTAG interface.
This datasheet describes the LM3S8970 microcontroller, covering its architecture, ARM Cortex‑M3 core, and a wide range of on‑chip peripherals such as GPIO, timers, UART, SSI, I²C, CAN and Ethernet. It includes block diagrams, functional descriptions, and register details for each module.
The document also contains electrical characteristics, packaging information, ordering details, and contact information for technical support and sales offices of ZLG across China. This manual is written in Chinese.
| CPU core | ARM Cortex‑M3 |
|---|
Contact ZLG technical support by phone (+86 (020) 22644358‑22644361) or email [email protected] during business hours.
Ordering information is listed in section C.1, which provides part numbers and descriptions for the LM3S8970 series.
The official website is www.zlgmcu.com.
