This manual explains the safety precautions and proper handling of the KDC-MP4026 CD changer, including power‑cable requirements, grounding, and protection against short circuits. It also covers installation steps, such as connecting the power supply and securing the unit with the supplied screws.
The guide details how to operate the device, including CD insertion, disc naming, MP3/WMA playback, supported file formats, and troubleshooting error codes. Technical specifications such as output power, frequency response, dimensions, and power consumption are listed at the end of the document. This manual is written in Japanese.
| Frequency response | 10 Hz – 20 kHz |
|---|---|
| Dimensions (W×H×D) | 182×53×155 mm |
| Maximum output voltage | 2000 mV/10 kΩ |
The unit can play MP3 (MPEG‑1/2 Layer‑3) and WMA files that have the .MP3 or .WMA extensions.
Use vehicle‑grade wiring of at least 0.75 mm² (AWG 18) or larger for the power connection.
It indicates that no disc is detected in the disc tray.
