The Johnson Controls J1B1B14MCT10 thermostat bulletin provides specifications, installation steps, wiring diagrams, and setting instructions.
This bulletin describes the J1B1B14MCT10 room thermostat, its operation principle, and the two versions (standard and cooling/heating switch). It explains the device’s contacts, range‑stop mechanism, and how it controls HVAC equipment.
The document includes detailed installation procedures, wiring examples for cooling and heating control, dimension data, and safety precautions for proper mounting and use. This manual is written in Japanese.
| Rated voltage | AC / DC |
|---|---|
| Temperature adjustment range | -30 °C to 130 °C |
| Instantaneous current | 0.45 A |
Turn the dial knob and align the scale to the desired temperature; the thermostat will adjust accordingly.
Press and hold the range‑stop while turning the dial; the temperature scale will stop at the selected limit.
Connect the thermostat’s contacts to the cooling system according to the standard wiring diagram (terminal 6‑6 for standard, 6‑13 for cooling/heating switch).
Perform all wiring with power off, follow electrical standards, and have a qualified technician handle the installation.
