This manual describes the operation of the Pioneer DEH-P5000UB CD Receiver. It covers basic operations such as turning the unit on/off, selecting a source, adjusting the volume, storing and recalling radio frequencies, and so on. Additionally, it introduces advanced operations such as displaying text information on discs, selecting tracks from the track title list, selecting files from the file name list, selecting a repeat play range, playing tracks in random order, scanning folders and tracks, pausing playback, and using Sound Retriever and Disc Title functions.
This manual explains how to operate the Pioneer DEH-P5000UB CD Receiver, covering basic functions such as power on/off, source selection, volume control, and use of the built‑in CD player, USB, iPod, Bluetooth and satellite radio features.
It also includes safety information, front‑panel removal and attachment instructions, remote‑control battery replacement, and a full specifications table detailing power requirements, audio output, dimensions and tuner ranges.
| Power source | 14.4 V DC (10.8 V to 15.1 V allowable) |
|---|---|
| Maximum current consumption | 10.0 A |
| Dimensions (W × H × D) | 178 × 50 × 162 mm |
| Weight | 1.5 kg |
| Audio maximum power output | 50 W × 4 |
| Load impedance | 4 W to 8 W |
| Pre‑out max output level | 4 V |
| CD player signal‑to‑noise ratio | 94 dB (1 kHz) |
| FM tuner frequency range | 87.9 MHz to 107.9 MHz |
| AM tuner frequency range | 530 kHz to 1 710 kHz |
Press the OPEN button, then grip the left side of the front panel and pull it gently outward.
Slide the tray on the back of the remote control out and insert a CR2025 (3 V) battery with the correct polarity.
The unit’s maximum current consumption is 10.0 A.
