The dsPIC30F family combines a 16‑bit microcontroller core with integrated DSP functionality, offering up to 30 MIPS performance, multiple interrupt sources, and a range of peripheral modules such as PWM, UART, CAN and ADC. It is targeted at applications that require high‑speed signal processing together with the control capabilities of a microcontroller.
The series is available in a variety of pin‑counts and package types (18‑pin to 80‑pin QFP, TQFP, QFN, SOIC, etc.), providing flexible memory options (up to 144 KB Flash, 4 KB EEPROM, 8 KB SRAM) and operating temperature ranges from –40 °C to 125 °C. Extensive software support and reference designs are offered through Microchip’s development tools and libraries. This manual is written in Chinese.
| CPU Performance | 30 MIPS |
|---|---|
| Supply Voltage (VDD) | 2.5 V to 5.5 V |
| Operating Temperature | -40 °C to 125 °C |
| Flash Program Memory | Up to 144 KB |
| EEPROM | Up to 4 KB |
| SRAM | Up to 8 KB |
| Maximum PWM Outputs | 8 |
The dsPIC30F family supports up to 144 KB of flash program memory.
The devices operate with a supply voltage (VDD) from 2.5 V to 5.5 V.
They are rated for –40 °C to 125 °C ambient temperature.
Up to 8 PWM channels are available depending on the specific device and package.
