Texas Instruments TPS65951 Integrated Power Management Audio Codec Data Manual

This document describes the features and characteristics of the TPS65951 Integrated Power Management/Audio Codec Silicon Revision 1.0 Version F.

Brand: Texas Instruments
Category: Power Management
Document type: Datasheet
Language: English
Pages: 170
File format: PDF
File size: 1.5 MB
Published: 08 April, 2013
Updated: 29 September, 2023
MD5 checksum: 767FF7E79B73210C19C666C5AE112A66
PDF: Texas Instruments TPS65951 Integrated Power Management Audio Codec Data Manual PDF

About this manual

The document provides a comprehensive technical overview of the TPS65951 Integrated Power Management/Audio Codec. It covers the device's block diagram, terminal descriptions, and detailed signal specifications including clock requirements and output characteristics.

Key sections include extensive details on the Audio/Voice Module for downlink (RX) and uplink (TX), covering earphone outputs, headset interfaces, microphone biasing, and digital filters. The Power Module section describes various DC-DC regulators, LDOs, battery monitoring, and power management modes such as Master/Slave and Boot Modes.

What's inside

Introduction
Terminal Description
Electrical Characteristics
Clock Specifications
Audio/Voice Module
Power Module
Connectivity
Battery Interface
LED Drivers
Package Information

Specifications

Product Type	Integrated Power Management/Audio Codec
Silicon Revision	1.0
Literature Number	SWCS053F
Publication Date	September 2010

Frequently asked questions

What is the literature number for this document?

The literature number assigned to this data manual is SWCS053F.

When was this datasheet revised?

This document was originally published in September 2010 and revised in May 2012.
