The MMA series of silicon capacitive, micromachined accelerometers features signal conditioning, a 4-pole low pass filter and temperature compensation. Zero-g offset full scale span and filter cut-off are factory set and require no external devices. A full system self-test capability verifies system functionality.
The MMA1200D is a surface‑micromachined silicon‑capacitive accelerometer with integrated signal conditioning, a 4‑pole Bessel low‑pass filter, and temperature compensation. It provides a linear, ratiometric output and includes a calibrated self‑test feature for verifying mechanical and electrical integrity.
The document details maximum ratings, operating characteristics, pin assignments, package dimensions, and recommended PCB layout. It also outlines ESD precautions, fault detection via the STATUS pin, and legal disclaimer information.
