The Roland DE-200 is a digital delay unit featuring a 12-bit quantizing system and an analog logarithmic compression system for high signal-to-noise ratios. It offers selectable stereo effects and a Rhythm Sync function to synchronize with external rhythm machines like the TR-606 or DR-110. The unit can also function as a sampler by holding recorded sounds.
The manual details the operation of the front and rear panel controls, including delay time range and fine adjustments, modulation settings, and feedback controls. It explains how to set up the unit for mono or stereo output, how to use the Hold function for overdubbing, and provides specific instructions for synchronizing the delay effect with a rhythm machine.
| Rated Input Level | -20 dBm |
|---|---|
| Maximum Input Level | +12 dBm |
| Total Harmonic Distortion | 0.08% (Direct), 0.25% (Delay) |
| Delay Time Range | 1.25 ms to 640 ms (x1), 2.5 ms to 1280 ms (x2) |
| Power Consumption | 13 W |
| Dimensions | 482(W) x 44(H) x 240(D) mm |
| Weight | 3.5kg/7lb 11oz |
Yes, by holding the sound you like, the unit can be used as an external sound source for a rhythm machine.
Connect the Rhythm Sync Jack to the Trigger Out Jack of the rhythm machine to start or resume the delay effect by an external trigger signal.
The rated input level is -20 dBm, so a preamplifier is required for microphone signals.
