This manual provides operating instructions for the BOSS DM-2, a delay pedal featuring continuous delay time control from 20ms to 300ms and a noise reduction circuit. It details the functions of the controls, including Repeat Rate, Intensity, and Echo Volume, as well as the FET switching system designed to prevent audible clicks.
| Delay time | 20ms ~ 300ms |
|---|---|
| Residual noise | Less than -100dBm (IHF-A) |
| Input impedance | 470kΩ |
| Output load impedance | Over 10kΩ |
| Dimensions | 70(W) x 55(H) x 125(D)mm |
| Weight | 450g |
The DM-2 can control delay time from 20ms to 300ms continuously.
The unit requires one 9-volt battery.
Check the LED indicator; if it fails to light or becomes dimmer, the battery should be replaced.
