This document provides information on the implementation and operation of the L100 Safety Locking Device, including safety, device description, functions, applications, mounting, electrical connection, testing, cleaning, disposal, service and support, accessories, and technical data.
This document serves as the primary guide for the safe implementation, testing, and operation of the Leuze L100 Safety Locking Device. It details the necessary safety precautions, proper use conditions, and responsibilities for both manufacturers and operators to ensure personnel protection.
| Protection rating | IP 66 |
|---|---|
| Housing material | glass-fibre-reinforced and non-combustible plastic |
The operator of the machine is responsible for instructing the operating personnel.
The device satisfies a protection rating of IP 66.
It uses a funnel-shaped insertion opening to ensure the actuator self-centers even if the door is slightly misadjusted.
This specific model uses mechanical locking with a spring force and includes a manual auxiliary release.
