This document introduces the operation methods of S200 safety switch, including installation, use and maintenance.
The Leuze electronic S200 Safety Switch is an electro-mechanical switching device designed for use in protective devices. It features a metal housing with an IP 67 protection rating and a funnel-shaped insertion opening that allows the actuator to self-center even if the door is slightly misadjusted. The device is available in various configurations, including different contact blocks (NC, 1 NC + 1 NO) and cable entries.
This document provides detailed instructions for the safe implementation, operation, and maintenance of the S200 Safety Switch. Key topics include risk evaluation according to standards like EN ISO 13849-1, proper mounting and adjustment of the deflection head, electrical connection of the contact block, and specific testing procedures to be performed prior to initial start-up and periodically thereafter.
| Protection rating | IP 67 |
|---|---|
| Device type | electro-mechanical switching device |
| Housing material | metal |
The dangerous state can only be activated while the protective device is closed.
The operator of the machine is responsible for instructing the operating personnel.
