This manual provides all the information on the FRENIC-Mini series of inverters including its operating procedure, operation modes, and selection of peripheral equipment. Carefully read this manual for proper use. Incorrect handling of the inverter may prevent the inverter and/or related equipment from operating correctly, shorten their lives, or cause problems. Listed below are the other materials related to the use of the FRENIC-Mini. Read them in conjunction with this manual as necessary.
This manual provides comprehensive information on the FRENIC-Mini series of inverters, including operating procedures, various operation modes, and guidelines for selecting peripheral equipment. It serves as a primary reference for the proper use and handling of the device to ensure correct operation and longevity.
The document includes critical safety precautions and usage guidelines, such as warnings regarding the use of the inverter with motors that depend on lives (e.g., nuclear, aerospace, medical) and specific instructions for running general-purpose and special motors. It also details environmental conditions, installation requirements, and precautions for combining the inverter with other devices.
The unit must be installed within an ambient temperature range from -10 to +50°C (+14 to 122°F).
You must use a 500 V megger to check the insulation resistance.
