Panasonic TU-DST52 HDTV Digital Receiver Operating Instructions

The document describes the features and characteristics of a product with the brand G79.

Brand: Panasonic
Category: Player
Document type: User Manual
Language: English
Pages: 44
File format: PDF
File size: 2.6 MB
Published: 03 August, 2012
Updated: 29 September, 2023
MD5 checksum: 762ECF1B4B6EB8D4EFB51BC241EBCF97
PDF: Panasonic TU-DST52 HDTV Digital Receiver Operating Instructions PDF

About this manual

This document provides operating instructions for the Panasonic TU-DST52 HDTV Digital Receiver. It includes important safety information, installation guidelines for location and cable connections, and setup procedures for connecting to HDTV monitors or NTSC receivers. The manual also details the use of the Roller Guide menu system and remote control programming.

What's inside

Important Safety Instructions
Specifications
Installation
HDTV Digital Receiver Location
Connecting Cables
Antenna Installation and Orientation
Front and Rear View
Display Format
Channel and Program Tuning
Remote Control Operation

Specifications

Power Source	120V AC, 60Hz
Channel Capability	ATSC/DTV
Digital Audio Output	Dolby Digital Fiber Optic
Video Output Jacks	1Vp-p, 75 Ohm, Phono Jack Type
Audio Output Jacks	0-2.0V RMS 4.7K Ohm
S-Video Out Jack	S-Video (Y-C) Connector

Frequently asked questions

What is the power requirement for the TU-DST52?

The receiver requires a power source of 120V AC at 60Hz.

What type of antenna is recommended for best results?

A directional antenna such as a Yagi, log periodic, or reflector antenna is recommended.

Can the receiver display high-definition formats?

Yes, when connected to an HDTV monitor/receiver, it can display 1080i format.
