SB-WA883YP is a subwoofer unit for home theater system.
The manual begins with safety warnings, emphasizing that only qualified personnel should perform repairs because improper work can cause serious injury or death. It also lists general precautions such as checking for short circuits and ensuring proper grounding before servicing.
Detailed disassembly procedures follow, describing how to remove the speaker cabinet, power board, amplifier board, and other internal components. The document includes dimensions, weight, operating temperature range, and a parts reference list for replacement components. This manual is written in Chinese.
| Dimensions | 248 mm × 417 mm × 476.6 mm |
|---|
The unit measures 248 mm wide, 417 mm high, and 476.6 mm deep.
