This document describes the features and characteristics of the ultra-compact control unit produced by Panasonic Electric Works. The control unit is small in size and suitable for miniaturization of machinery, equipment, and control cabinets. It can be expanded to a maximum of 128 points using expansion units and has USB2.0 and RS232C ports. It has a large program capacity and independent annotation memory, making program maintenance and management convenient.
The FPOR is a compact, high‑performance PLC with up to 32 k program steps and 32 k words of data registers. It offers fast 80 ns/step execution, multiple high‑speed counters, PWM outputs, and built‑in FRAM for battery‑free data backup. The unit’s small size (90 mm × 25 mm) allows installation in tight spaces and can be expanded to control up to 128 I/O points.
Programming is performed via Panasonic’s FPWIN Pro/GR tools over USB 2.0 or RS‑232C ports. The manual describes wiring, network options (CC‑Link, C‑NET, Ethernet), and advanced functions such as JOG positioning, multi‑axis control, and PID temperature regulation. It also covers optional modules, safety features, and troubleshooting procedures. This manual is written in Chinese.
| Program capacity | 32 k steps |
|---|---|
| Data register size | 32 k words |
| Maximum pulse output frequency per axis | 50 kHz |
| Program execution speed | 80 ns per step (ST instruction) |
| USB programming ports | USB 2.0 (mini‑B) and RS‑232C |
| Built‑in memory backup | FRAM, no battery required |
The FPOR can store up to 32 k program steps.
Each axis can output pulses up to 50 kHz.
The unit includes a USB 2.0 mini‑B port and an RS‑232C port for programming.
