The Tag-it HF-I Transponder Inlay is a passive RFID device compliant with the ISO/IEC 15693 standard. It features a user memory of 2k bits organized in 64 blocks and is designed for applications such as product authentication, ticketing, library management, and supply chain management. The inlay is thin and flexible, allowing it to be easily converted into paper or plastic labels.
| Supported Standard | ISO 15693-2, -3 |
|---|---|
| Recommended Operating frequency | 13.56 MHz |
| Passive Resonance Frequency (at +25°C) | 13.86 MHz + 200kHz |
| Memory (user programmable) | 2k bits |
| Typical programming cycles (at +25°C) | 100,000 |
| Data retention time (at +55°C) | > 10 years |
| Operating temperature | -25°C to +70°C |
| Storage temperature (single inlay) | -40°C to +85°C |
| Antenna size | 45 mm x 76 mm |
| Base material Substrate | PET |
The user memory is 2k bits organized in 64 blocks.
The recommended operating frequency is 13.56 MHz.
