Fairchild FDMF6730 Driver plus MOSFET Datasheet

The FDMF6730 is a high efficiency driver plus MOSFET power stage solution optimized for Ultra Mobile PC (UMPC) system power voltage supplies. It is fully compliant with the Intel Ultra- Mobile Driver MOS (uDrMOS) Specification.

Brand: Fairchild
Category: Power Management
Document type: Datasheet
Language: English
Pages: 10
File format: PDF
File size: 282 KB
Published: 12 July, 2012
Updated: 01 October, 2023
MD5 checksum: A83A075199FD0442759FE9C6800BD266
PDF: Fairchild FDMF6730 Driver plus MOSFET Datasheet PDF

About this manual

The FDMF6730 is a high-efficiency Driver plus MOSFET power stage solution designed for Ultra Mobile PC (UMPC) system power voltage supplies. It complies with the Intel Ultra-Mobile Driver MOS (uDrMOS) Specification and features over 95% efficiency with an internal SV regulator for gate drive.

What's inside

Features
Applications
General Description
Functional Block Diagram
Pin Configuration
Pin Description
Absolute Maximum Rating
Recommended Operating Range
Electrical Characteristics
Description of Operation

Specifications

Input Voltage Range	6-16 V
Max Operating Frequency	1 MHz
Continuous Current (Low Side)	5 A
Max Output Current (with PASS FET)	10 A
Package Type	6x6 Power QFN
Operating Junction Temperature Range	-55 to 150 C

Frequently asked questions

What is the typical application for this device?

It is optimized for Ultra Mobile PC (UMPC) system power voltage supplies.

Does the module include an integrated bootstrap diode?

Yes, the device includes an integrated bootstrap diode within the IC.
