The document is about the technical data of Stromag products, stating that application-specific factors can only be adequately considered through testing in actual use.
This document provides technical specifications and connection diagrams for the Stromag NFA160/250-V brake. It includes electrical output data such as release and holding currents, as well as mechanical parameters like break torque and air gap settings.
The text details the installation process, specifying the use of microswitches, sealing measures, and specific screw types for mounting. It also notes that the technical data are calculation results and recommends customer-specific testing for application-specific factors. This manual is written in German.
| Holding current | 1.94 A |
|---|---|
| Break torque | 2500 Nm |
| Air gap off norm | 0.5 mm |
| Max air gap | 1.5 mm |
| Voltage | 230/400 V |
| Frequency | 50 Hz |
| Mounting torque | 7.3 Nm |
| Air gap out norm | 0.6 mm |
The holding current is 1.94 A.
The break torque is 2500 Nm.
The recommended air gap is 0.5 mm.
