This document provides technical data for Rexnord RNA21 and RNG21 series parallel shaft gearboxes. It includes dimensional drawings and tables specifying key geometric parameters such as center distances, face widths, and mounting hole positions. The text contains detailed specification tables comparing different models (RNA21, RNB21, RNG24, etc.) with numerical values for various dimensions labeled A through K. It also references compliance with DIN 6895 standards.
| Series Models Covered | RNA21, RNB21, RNG24, RND21, RNE21, RNF21, RNG21 |
|---|---|
| Standard Compliance | DIN 6895 |
The document specifies that the unit is designed for old horizontal mounting.
This model features two stages of gearing.
