This document is a technical datasheet for the Rexnord model 9670-50-003 miniature coupling. It provides specific performance parameters required by DIN 740 standards.
Key specifications include a nominal torque of 2.7 Nm and a maximum torque of 15 Nm. The coupling supports axial misalignment up to 1.6 mm, radial misalignment is variable based on the model, and angular misalignment is rated at 2 degrees.
| Nominal Torque (TK) | 2.7 Nm |
|---|---|
| Maximum Torque (Tkmax) | 15 Nm |
| Axial Misalignment (Aka) | 1.6 mm |
| Angular Misalignment (Akw) | 2 deg |
| Maximum Speed (Nmax) | 45000 rpm |
| Moment of Inertia (J) | 0.00004 kgm2 |
The maximum torque (Tkmax) is rated at 15 Nm.
The maximum speed (Nmax) for this coupling is 45,000 rpm.
The coupling allows a maximum axial misalignment of 1.6 mm and an angular misalignment of 2 degrees.
