BL 981411-0 and BL 981411-1 are panel-mounted pH indicators and controllers designed for simplicity of use in a wide range of industrial applications.
This manual provides instructions for the Hanna BL 981411-0 and BL 981411-1, which are panel-mounted pH indicators and controllers designed for industrial applications. The devices feature a multi-colour LED indicator, an overtime control system, and selectable dosing directions (Acid or Alk). The BL 981411-0 model operates on 12 Vdc, while the BL 981411-1 operates on 115 or 230 Vac.
| Range | 0.0 to 14.0 pH |
|---|---|
| Resolution | 0.1 pH |
| Accuracy | +/-0.2 pH at 20°C/68°F |
| Power Consumption | 10 VA |
| Dimensions | 83 x 53 x 99 mm |
The instruments are warranted for two years against defects in workmanship and materials.
Dosing direction (Acid or Alk) is selectable on the back panel.
The maximum dosing contact current is 2A.
