This document describes the features and usage of the R10CE Universal Monitoring D/A Converter R-series Card Module.
The AJA R10CE is an R-series card module designed as a Universal Monitoring D/A Converter. It accepts an SDI input and provides four equalized, re-clocked serial digital outputs, plus four analog monitoring outputs. One analog output is fixed for NTSC/PAL, while the other three are configurable to various formats including composite, Y/C (S Video), component (SMPTE/N10, RGB, Betacam), or 3x NTSC/PAL.
| Input | SDI (SMPTE 259M), BNC |
|---|---|
| Serial Outputs | 4 x BNC |
| Analog Outputs | NTSC/PAL, 1 x BNC |
| Configurable Analog Outputs | YPbPr - SMPTE, EBU-N10, Betacam, RGB, or 3 x NTSC/PAL, or 1 NTSC/PAL and Y/C (S Video) |
| Output Buffering | All outputs are separately buffered |
| Serial Output Characteristics | Equalized, Re-clocked |
| Jitter Filtering | Up to 2.5 Hz |
| Frequency Response | +/-25db to 5Mhz frequency response (Y) |
The device automatically configures to 525 or 625 line component digital inputs and outputs analog NTSC or PAL based on the input.
The unit automatically configures to 525 or 625 line component digital inputs and then outputs analog NTSC or PAL based on the input.
