This document is a technical specification table for SXV 450 – 550 Van Den Bosch Replica
This document provides technical specifications and adjustment instructions for the Aprilia SXV 450-550 VDB Replica. It details settings for the Marzocchi front forks and Sachs rear shock absorber, including hydraulic brake adjustments and spring rates.
The manual includes specific procedures for starting the vehicle using an external battery, adjusting remote brake levers, and managing launch control via fork compression. It also covers maintenance tasks such as chain tensioner adjustment, steering angle regulation, and clutch system servicing. This manual is written in Italian.
| Front Fork Type | Marzocchi Shiver 50 |
|---|---|
| Front Fork Travel | 267mm |
| Rear Shock Type | Mono Sachs racing |
| Rear Shock Travel | 120mm |
| Standard Primary Spring (450) | 130 kg |
| Standard Secondary Spring (450) | 40 kg |
An external battery supplied with the vehicle is necessary for cold starting.
Adjustment is done by acting on the adjustment knob located on the left handlebar.
Changing the direction of the chain tensioner pads corresponds to one tooth on the sprocket.
