RM-B750 remote control user manual, introduces the use of the remote control, precautions, warnings, etc.
The Sony RM-B750 is a remote control unit designed for the adjustment functions of Sony BVP/HDC series broadcast CCD color video cameras. It allows operators to control camera functions from a distance of up to 50 meters using a dedicated cable. The unit features a touch panel and a 3.5-inch LCD display to select and change various settings, as well as to display camera menu items from the viewfinder.
Key features include VTR control for tape transport, automatic adjustment of white balance and black balance, control of ECS (Extended Clear Scan) and electronic shutter functions, and support for the S-EVS (Super Enhanced Vertical Definition System) function. The unit also includes a Memory Stick slot for saving and reproducing scene and reference files, and can be used in parallel with other control panels or attached to the HDCU-950 unit. This manual is written in Japanese.
| Maximum Control Distance | 50 m |
|---|---|
| Display Type | 3.5-inch LCD |
The unit can be used up to 50 meters away from the camera when connected with the dedicated cable.
The unit allows you to use it up to 50 meters away from the camera when connected with the included cable.
The unit cycles through FULL mode, PART mode, and LOCK mode each time the button is pushed.
