Thermo Electron's SpectraSYSTEM™ LC, one of the world's most popular LC systems, can be fully controlled through both the EZChrom Elite CDS and Agilent OL Operating System for the Laboratory. This system includes pumps, autosamplers, UV detectors, fluorescence detectors, and PDA detectors, which can be controlled through this optional instrument control software.
The Agilent EZChrom Elite CDS and Agilent OL Operating System provide full digital control for Thermo Electron's SpectraSYSTEM LC family. This includes support for pumps, autosamplers, UV detectors, fluorescence detectors, and PDA detectors. The software features intelligent auto-configuration to identify connected modules without user intervention.
| Required Interface Model | SN4000 |
|---|---|
| Supported Pumps | P1000, P1500, P2000, P4000 |
| Supported Autosamplers | AS1000, AS3000, AS3500, AS2000, HS2000 |
| Supported Detectors (UV) | UVE000LP, UV1000, UV2000, UV3000 |
| Supported Detectors (Fluorescence) | FL2000, FL3000 |
Up to four non-PDA systems or up to two with PDA.
Control is established via RS232, requiring a serial port for the SN4000 interface and an additional serial port for specific detectors.
