This document describes the features and characteristics of the LAGOON ™ LAGOON MANUAL TM product.
The M-Audio Lagoon is a low-profile PCI digital audio card designed for high-quality digital audio processing on PC systems. It features an onboard Motorola 56301 DSP running at 80 MHz with 768 kBytes of fast EDO-DRAM to support simultaneous recording and playback.
| DSP Processor | Motorola 56301 running at 80 MHz, delivering 80 MIPS computing power. |
|---|---|
| Memory | 768 kByte fast EDO-DRAM |
| S/PDIF Sample Rates | 32, 44.1, 48, 64, 88.2, 96 kHz |
| ADAT Sample Rates | 39 kHz to 51 kHz |
The computer must have a Pentium 166 or higher with MMX, and at least 32 MByte of RAM (64 MByte recommended).
Close jumper K9 when using the LAGOON MIDI cable for proper shielding, and leave it open when using an ADAT Sync cable to avoid ground loops.
Yes, the card supports Mixed Mode where S/PDIF In and ADAT Out or ADAT In and S/PDIF Out can occur simultaneously.
