The Panasonic WX-RP921 is a wireless antenna designed for indoor use with diversity receivers (WX-RP810/WX-RP820) or distributors (WX-RP900). It features a built-in down converter from 800MHz to 260MHz and includes a pre-amplifier to compensate for coaxial cable loss. The unit operates on phantom power supplied via the coaxial cable.
| Power Source | Supplied from Diversity Receivers WX-RP810 or WX-RP820 or Distributor WX-RP900, 12V DC |
|---|---|
| Receiving Frequency | 797MHz to 803MHz |
| Ripple | Less than 3dB |
| Output Impedance | 75 ohms |
| Antenna Type | 1/4 Wavelength Whip Antenna |
No, it is designed strictly for indoor use.
Set the Attenuator selection switch to the 10dB position.
