The Agilent 1260 Infinity Bio-inert LC is a fully bio-inert liquid chromatography system designed for bio-molecule analysis. The entire flow path of the system is bio-logically inert, minimizing secondary interaction of proteins and peptides with metallic surfaces. It offers true UHPLC performance, capable of handling high pressures up to 600 bar and compatible with SEC and IEX columns with particle sizes down to 1.7 µm. Additionally, it provides 10 times higher detection sensitivity, allowing for analysis of minor components in complex mixtures with smaller sample amounts.
The Agilent 1260 Infinity Bio-inert Quaternary Liquid Chromatography (LC) system is designed to set new standards in performance and reliability for the analysis of bio-molecules. It features a completely metal-free flow path using ceramics or PEEK materials to minimize non-specific binding, peak tailing, and sample loss associated with metallic surfaces.
The system offers true Ultra-High Performance Liquid Chromatography (UHPLC) capability with pressure ratings up to 600 bar, making it suitable for columns with particle sizes down to 1.7 µm. Key components include a quaternary pump with titanium solvent lines, a high-performance autosampler capable of handling microtiter plates and volumes from 0.1 µL to 900 µL, and various bio-inert detectors such as the Max-Light Diode Array Detector.
| Pressure Range | up to 600 bar |
|---|---|
| Particle Size Support | down to 1.7 µm |
| Flow Rate (Gradient) | up to 10mL/min |
| Injection Volume Range | 0.1 µL to 900 µL |
| Column Length Support | up to 30 cm |
All capillaries and fittings throughout the autosampler, column compartment and detectors are completely metal-free so that the bio-molecules in your sample come in contact only with ceramics or PEEK.
Yes, it handles buffers with high salt concentrations such as 2 M NaCl or 8M urea and extreme pH values of 1-13.
The system provides true UHPLC performance up to 600 bar.
