Yamaha YST-M8 Powered Multimedia Speakers User Manual

YST-M8 is a powered multimedia speaker from Panasonic

Brand: Yamaha
Category: Home Speakers
Document type: User Manual
Language: English
Pages: 9
File format: PDF
File size: 88 KB
Published: 03 July, 2012
Updated: 30 September, 2023
MD5 checksum: B90D8D3EC1AEBFAF51DD3DDCFC28388A
PDF: Yamaha YST-M8 Powered Multimedia Speakers User Manual PDF

About this manual

This document is the Owner's Manual for the Yamaha YST-M8 Powered Multimedia Speakers. It covers safety instructions, system connection examples, and detailed descriptions of the front and rear panel controls and inputs. The manual explains how to power on the unit, adjust volume and tone, and connect various audio sources such as CD players and personal computers.

What's inside

Safety Instructions
System Example
Front & Rear Panel
Cautions
Connections
Controls
Specifications
Non skid Pads

Specifications

Output power	5 W+5 W
Input sensitivity	200 mV
Input Impedance	25 kQ
Frequency response	80 Hz to 20 kHz
Speaker unit	6.5 cm (2.5") full-range cone
Output Impedance	600 2
Power supply	DC 12V
Dimensions (WxHxD)	86 x 216 x 130 mm

Frequently asked questions

What is the output power of the YST-M8?

The output power is 5 W+5 W at 1 kHz and 4 Q.

How do I turn on the YST-M8?

Press the power switch to turn on the unit; the indicator will light up.

What is the function of the TONE control?

It allows frequency boost and cut up to +7 dB at 10 kHz to emphasize vocals.
