The Yamaha KX5 is a remote keyboard designed to connect with electronic instruments featuring MIDI connectors, such as the Yamaha DX series. It allows users to perform stand-up performances by controlling up to 64 voices from an internal memory bank.
Key features include full initial and after-touch sensitivity for dynamic control, two-octave transpose capability, and direct access to voice banks. The device also offers modulation and volume thumbwheels, a pitch bend ribbon controller, and portamento effects.
| Keyboard Range | 37 keys C2 ~ C5 |
|---|---|
| Tone Selectors | BANK (1 ~ 4), VOICE (1~ 8) |
| Controls | SUSTAIN, PORTAMENTO, MODE, TRANSPOSE, MIDI |
| Power Source | 6 'AA' or R6 Battery |
| Battery Life | 7 hours in continuous use |
| Dimensions (WxHxD) | 914 x 80x 191mm |
| Weight | 3.7kg (8.2 Ibs.) |
Turn the receiving keyboard ON first, then turn ON the KX5.
The KX5 requires six 'AA' or R6 batteries.
Battery life is approximately 7 hours in continuous operation.
