The Yamaha MS202 is a bass reflex powered speaker featuring two 4-inch full-range speakers designed for home recording or practice. It utilizes magnetic field-canceling technology to allow placement next to televisions without interference. The unit includes tone controls for low and high frequencies, master volume adjustment, and separate inputs for microphones and line-level instruments.
| Type | Bass Reflex Powered Speaker |
|---|---|
| Frequency Range | 70 Hz - 18 kHz (Tone Con. : Flat) |
| Max. SPL | 103 dB SPL (20W, 1m on axis) |
| Dimensions | 292 x 214 x 198 mm (11-1/2 x 8-3/8 x 7-3/4 in) |
| Weight | 3.9 kg (8 Ib 6 02) |
| Components | JA1060 [10cm (4in), Cone] x 2 |
| Output Power | 20 W at 1 kHz, THD=0.5%, RL=4Ω |
| Input Sensitivity (MIC) | -50 dB / 10 kΩ/ Phone Jack |
Yes, because it uses magnetic field-canceling speakers that do not interfere with the picture.
The unit requires AC120 V at 60 Hz.
Turning left boosts low frequencies (100Hz) up to +12dB max, while turning right boosts high frequencies (10kHz) up to +12dB.
