Burr-Brown OPA21 Operational Amplifier Datasheet

This datasheet provides the characteristics and specifications of the OPA21 op-amp.

Brand: Burr-Brown
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 7
File format: PDF
File size: 307 KB
Published: 02 July, 2012
Updated: 01 October, 2023
Model: OPA21
MD5 checksum: B2EED61C083A71FF93506DA6FD4ED850
PDF: Burr-Brown OPA21 Operational Amplifier Datasheet PDF

About this manual

This document is a technical datasheet for the Burr-Brown OPA21, a low-power precision operational amplifier designed for instrumentation-grade performance. It highlights features such as low supply current (6.9mW at +15V), wide supply range (+2.5V to +18V), and low offset voltage drift.

What's inside

Features
Applications
Specifications
Absolute Maximum Ratings
Pin Configuration
Ordering Information

Specifications

Supply Current (Vcc = +15V)	6.9mW
Offset Voltage Drift	1.0µV/°C max
Supply Range	+2.5V to +18V
Operating Temperature Range	-55°C to +125°C

Frequently asked questions

What is the maximum supply voltage?

The absolute maximum rating for supply voltage is 18V.

Is the OPA21 internally compensated?

Yes, it is internally compensated for unity-gain stability.
