Yamaha VAF2-2112(W) Array Frame Owner's Manual

About this manual

This manual provides safety precautions and installation instructions for the Yamaha VAF2-2112(W) Array Frame. It details how to properly mount angle indicator plates and eye bolts to suspend the speaker cluster assembly securely.

The document outlines a step-by-step process for determining splay angles, attaching hardware to the rear and front inserts, flipping the unit upside down, and finally suspending the assembly using M10 eye bolts.

What's inside

• Precautions
• Package Contents
• Installation Instructions
• Angle Indicator Plate Installation
• Eye Bolt Suspension

Frequently asked questions

What is the maximum splay angle for this speaker array frame?

The manual states that the configuration supports a maximum splay of 60 degrees.

Which specific eye bolts must be used to suspend the speaker cluster?

You must use only the M10 eye bolts included with the speaker unit for suspension.

What is the required procedure before adjusting the angle or direction of a speaker?

Always loosen the corresponding screw before making any adjustments to the angle or direction.
