Yamaha CLP-320 Digital Piano MIDI Data List

About this manual

This document provides a comprehensive data list for the Yamaha Clavinova CLP-320 digital piano. It details the specific hexadecimal formats required for transmitting and receiving MIDI messages.

The guide covers standard MIDI events such as Note On/Off, Control Change (including Bank Select, Modulation, and Volume), and Program Change numbers specific to the instrument's voices like Grand Piano and E.Piano. Additionally, it outlines System Realtime Messages, System Exclusive messages for Yamaha ID (XG Standard and Digital Piano formats), and Master Tuning parameters.

What's inside

• MIDI Data Format
• Note On/Off Events
• Control Change Parameters
• Program Change Numbers
• Pitch Bend Change
• System Realtime Messages
• Universal System Exclusive
• XG Standard Messages
• Digital Piano MIDI Format
• Master Tuning Table

Specifications

Frequently asked questions

What is the data format for a Note On event?

The format is [9nH] > [kkH] > [vwH], where n is the channel number, kk is the note number, and v is the velocity.

Which control change number sets the Main Volume?

Control Change number 07H (Main Volume) uses Parameter Data Range 07H for Volume MSB.

What is the Program Change number for Grand Piano?

The Program Change number for Grand Piano is 122, with MSB 0 and LSB 1.

How does the instrument handle a General MIDI Mode On message?

When received, the MIDI system resets to default settings and requires approximately 50ms to execute.
