The OPA358 is a high-performance, low-power, single-supply amplifier. It offers wide bandwidth, high gain, low distortion and is ideal for use in digital cameras, mobile phones, digital media players, video surveillance, optical power monitoring, and other applications.
The OPA358 is a high-speed operational amplifier optimized for 3V single-supply operation, featuring an 80MHz bandwidth and 55V/µs slew rate. It is designed for applications such as digital still cameras, camera phones, and digital video cameras where low power consumption and small package size are critical.
The device offers rail-to-rail output swing and includes a shutdown feature to reduce quiescent current to less than 5µA. It is available in the SC70-6 package, which is noted as the smallest package currently available for video applications.
| Bandwidth | 80MHz |
|---|---|
| Slew Rate | 55V/us |
| Supply Voltage Range | +2.7V to +3.3V |
| Package Type | SC70-6 |
| Quiescent Current | 5.2mA |
| Shutdown Current | < 5µA |
The OPA358 is optimized for supply voltages from +2.7V to +3.3V, with an operating range of +2.5V to +3.6V.
The OPA358 is available in the SC70-6 package.
